RS5100 Ring Scanner SE4770 Standard No
RS5100 Ring Scanner SE4770 Standard No
Product Overview
RS5100 Ring Scanner SE4770 Standard Battery Double Trigger No USB Top Trigger Bluetooth 5.0 Worldwide
- Bluetooth technology - Allows compatibility with most of your smart devices
- With Bluetooth technology, you can scan barcodes and then transmit data from the base
- Perfect for applications that require direct association with a workstation or a notebook
- Wired connectivity makes this scanner ideal for retail and desktop applications
- LED aimer is a perfect choice for patient-facing applications
Technical Specifications
Network & Communication
| Bluetooth | Yes |
Battery Information
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Capacity | 480 mAh |
| Battery Included | Yes |
Physical Characteristics
| Weight (Approximate) | 70 g |
| Form Factor | Wearable |
| Length | 67.8 mm |
| Width | 27.9 mm |
| Depth | 21.1 mm |
| Rugged | Yes |
Technical Information
| Connectivity Technology | Cable |
| Light Source | LED |
| Scan Mode | Trigger |
| Illumination Color | Red |
| Scan Engine Model | SE4770 |
| Scanning Capability | 2D |
| 1D | |
| Field of View (Horizontal) | 48° |
| Field of View (Vertical) | 30° |
| Reading Angle (Skew) | 60° |
| Reading Angle (Pitch) | 60° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 1077639 lux |
| Minimum Element Resolution (Code 39) | 0.08 mm |
| Maximum Element Resolution (Code 39) | 0.51 mm |
| Maximum Element Resolution (DataMatrix) | 0.25 mm |
| Minimum Element Resolution (PDF417) | 0.13 mm |
| Maximum Element Resolution (PDF417) | 0.17 mm |
| Air Electrostatic Discharge (+/-) | 15kV DC |
| Contact Electrostatic Discharge (+/-) | 8kV DC |
| Image Sensor Resolution | 1280 x 960 |
General Information
| Product Type | Barcode Scanner |
| Manufacturer Part Number | RS51C0TBDNWR |
| Manufacturer Website Address | http://www.zebra.com/ap/en.html |
| Manufacturer | Zebra Technologies Corporation |
| Product Model | RS5100 |
| Product Name | RS5100 Barcode Scanner |
| Brand Name | Zebra |
Miscellaneous
| Application/Usage | Picking |
| Warehouse | |
| Transportation | |
| Sorting | |
| Distribution | |
| Hospitality | |
| Logistics | |
| Manufacturing | |
| Packing | |
| Route Accounting | |
| Environmentally Friendly | Yes |
| Ingress Protection (IP) Rating | IP65 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
