Product Overview
APC by Schneider Electric Smart-UPS Line-interactive UPS - 3 kVA/2.70 kW - 2U Rack-mountable - 3 Hour Recharge - 3.20 Minute Stand-by - 230 V Input - 230 V AC Output - 1 x IEC 320-C19, 3 x IEC Jumper, 8 x IEC 320-C13 - Sine Wave - 12 x Battery/Surge Outlet - SmartConnect
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 3kVA line interactive 2U rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with IEC 320 C20 input, BS1363A British and Schuko CEE 7/EU1-16P input cables, 8 IEC 320 C13 and 1 IEC 320 C19 outlets, and 3 IEC jumper cables. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMT UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. It is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications.
- Experience higher efficiency with lower energy cost
- Up to 3.20 minute runtime on full load to preserve critical data from power shortage interruptions
- 3 kVA load capacity provides sufficient backup during power failures
- 2.70 kW load capacity - backup power for your valuable electronics
Technical Specifications
Network (RJ-45) | Yes |
Network Management | SmartConnect |
Battery Chemistry | Lead Acid |
Hot Swappable | Yes |
Backup/Run Time (Full Load) | 3.20 Minute |
Typical Battery Recharge Time | 3 Hour |
Input Voltage | 230 V |
Output Voltage | 230 V AC |
Waveform Type | Sine Wave |
Input Voltage Range | 160 V AC - 286 V AC |
Load Capacity (VA) | 3 kVA |
Load Capacity (Watt) | 2.70 kW |
Weight (Approximate) | 44.28 kg |
Rack Height | 2U |
Height | 86 mm |
Width | 432 mm |
Depth | 683 mm |
Mounting Location | Front |
Mounting Preference | No Preference |
Product Type | Line-interactive UPS |
Manufacturer Part Number | SMT3000RMI2UC |
Manufacturer Website Address | http://www.schneider-electric.com.au |
Manufacturer | Schneider Electric SA |
Product Name | Smart-UPS 3kVA Rack-mountable UPS |
Product Line | Smart-UPS |
Product Series | SMT |
Brand Name | APC by Schneider Electric |
Cord Length | 2 m |
Receptacle Type | IEC 60320 C13 |
IEC 60320 C19 | |
IEC Jumper | |
Number of Battery & Surge Outlets | 12 |
Transfer Time | 10 ms |
Receptacle Detail | 8 x IEC 320-C13 |
3 x IEC Jumper | |
1 x IEC 320-C19 |
Environmentally Friendly | Yes |
Mercury Free | Yes |
Optimized Energy Efficiency | Yes |
Product Take Back Program | Yes |
RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SMT3000RMI2UC_ROHS_DECLARATION&p_FileName=SMT3000RMI2UCKIT_ROHS_DECLARATION_US.pdf |
REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=490326943&lang=en-us |
EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=490326943&lang=en-us |
Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1612029_EN |
End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1612029_EN |
REACH free of SVHC | No |
