APC Smart-UPS X 3000VA Short Depth Tower
APC Smart-UPS X 3000VA Short Depth Tower
Product Overview
Schneider Electric Smart-UPS Line-interactive UPS - 3 kVA/2.70 kW - 4U Rack/Tower - 3 Hour Recharge - 6.30 Minute Stand-by - 208 V, 230 V Input - 230 V AC Output - 2 x IEC 320-C19, 2 x IEC Jumper, 8 x IEC 320-C13 - Serial Port - USB
This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 3kVA line interactive 4U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with IEC 320 C20 input (includes BS1363A, IEC 320 C20 and Schuko CEE 7/EU1-16P power cords), 8x IEC 320 C13 and 2x IEC 320 C19 outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.- Experience higher efficiency with lower energy cost
- Up to 6.30 minute runtime on full load to preserve critical data from power shortage interruptions
- 3 kVA load capacity - work without any interruption during power outages
- Prevent critical data loss by staying powered during a blackout with up to 2.70 kW load capacity
Technical Specifications
Controls/Indicators
| Status Indicators | LED status display with On Line : On Battery : Replace Battery and Overload indicators, Multi-function LCD status and control console |
Environmental Conditions
| Thermal Dissipation | 184 BTU/h |
| Sound Emission (A-Weighted) | 55 dB(A) |
Interfaces/Ports
| USB | Yes |
| Serial Port | Yes |
| Total Number of Expansion Slots | 1 |
Management
| Alarm | Configurable Delay |
| Low Battery | |
| On Battery |
Battery Information
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 18 Minute |
| Backup/Run Time (Full Load) | 6.30 Minute |
| Battery Characteristics | Spill-proof, Maintenance-free |
| Typical Battery Recharge Time | 3 Hour |
Power Description
| Input Voltage | 208 V |
| 230 V | |
| Output Voltage | 230 V AC |
| Waveform Type | Sine Wave |
| Load Capacity (VA) | 3 kVA |
| Load Capacity (Watt) | 2.70 kW |
General Information
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | SMX3000HV |
| Manufacturer Website Address | http://www.schneider-electric.com.au |
| Manufacturer | Schneider Electric SA |
| Product Name | Smart-UPS X 3000VA Rack/Tower LCD 200-240V |
| Product Line | Smart-UPS |
| Product Series | SMX |
| Brand Name | Schneider Electric |
Technical Information
| Emergency Power OFF | Yes |
| Cord Length | 1.83 m |
| Receptacle Type | Schuko CEE 7/EU1-16P |
| Receptacle Detail | 2 x IEC Jumper |
| 8 x IEC 320-C13 | |
| 2 x IEC 320-C19 |
Physical Characteristics
| Weight (Approximate) | 38.64 kg |
| Rack Height | 4U |
| Height | 432 mm |
| Width | 178 mm |
| Depth | 483 mm |
| Product Color | Black |
| Color Family | Black |
| Mounting Location | Front |
| Mounting Preference | Lower |
