Product Overview

Powerware Quickmov SPDQM1 Surge Suppressor/Protector - 800 J - 250 V AC, 440 V AC - Input250 V AC, 440 V AC Output - 60 kA

The QUICKMOV surge diverter is designed to provide point-of-entry protection against surge transients for services rated at 100A or greater. The unit is intended for installation at the M.E.N. point, or to be used in conjunction with an SPD50NGi Neutral-Earth protector in non-M.E.N. locations (contact Eaton Powerware for details). One QUICKMOV per phase is required for multi-phase installations.

Due to inbuilt protection mechanisms, no external fuse or circuit breaker is required. In fact, no other parts, apart from the Quickmov itself are required for installation - the unit simply installs like a standard QUICKLAG device, except with the free terminal being replaced with a short length of cable. This cable is connected to the Neutral bar of the switchboard.

The QUICKMOV has been designed in accordance with AS3100, ANSI-IEEE C62.41, IEC61643-1, IEC61000-6-1, 2, 3, 4 and other standards and codes as applicable.

  • Protect your electronic devices, home entertainment system and your appliances from serious power surges
  • 800 J offers great protection against surges and line noise

Technical Specifications

Miscellaneous
Additional Information
    • Residual voltage (Vpl) @ 3kA: 1.1kV (cable trimmed to 250mm)
    • Maximum Continuous Over Voltage (MCOV): 300VAC
    • Surge current rating In (20 times): 30kA (8/20us)
    • Temporary Over Voltage (TOV) (5s): 330VAC
Compatibility
    • Powerware Cutler-Hammer Quicklag-style Switchboard
    • Powerware SPD50NGi Surge Protector
    • Computer System
    • UPS
Country of OriginAustralia
General Information
Product TypeSurge Suppressor/Protector
Manufacturer Part NumberSPDQM1
Manufacturer Website Addresshttp://www.eatoncorp.com.au
ManufacturerEaton Corporation
Product ModelSPDQM1
Product NameQuickmov SPDQM1 Surge Suppressor
Product LineQuickmov
Brand NamePowerware
Physical Characteristics
Weight (Approximate)310 g
Height93 mm
Width25 mm
Depth71 mm
Power Description
Input Voltage250 V AC
440 V AC
Output Voltage250 V AC
440 V AC
Surge Energy Rating800 J
Maximum Surge Current60 kA
