Product Overview

APC Smart-UPS On-Line, 3kVA, Lithium-ion, Rackmount 3U, 230V, 6x C13+2x C19 IEC outlets, Network Card, Extended runtime, with rail kit

Smart-UPS On-Line

High density, double-conversion on-line power protection with scalable runtime

Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The Smart-UPS On-Line family provides customers with a reliable source of uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

  • 3 kVA load capacity - work without any interruption during power outages
  • Prevent critical data loss by staying powered during a blackout with up to 2.70 kW load capacity

Technical Specifications

Controls/Indicators
Status Indicators
    • LCD Graphics Display
    • LED Status Indicators
    • Audible and Visible Alarms
Management
Network ManagementSNMP Manageable
Miscellaneous
Environmentally FriendlyYes
Interfaces/Ports
Network (RJ-45)Yes
EPO PortYes
USB (HID Compliant) PortYes
Battery Information
Battery ChemistryLithium Ion (Li-Ion)
Hot SwappableYes
Number of Batteries1
Replaceable BatteryYes
Environmental Conditions
Thermal Dissipation317 BTU/h
Maximum Operating Temperature40°C
Maximum Operating Elevation3 km
Maximum Storage Elevation15 km
Sound Emission (A-Weighted)50 dB(A)
Technical Information
Application/UsageLab Equipment
Medical
Server
Voice/Data Network
Industry
Receptacle TypeIEC 60320 C13
IEC 60320 C19
Receptacle Detail6 x IEC 60320 C13
2 x IEC 60320 C19
Physical Characteristics
Weight (Approximate)22 kg
Rack Height3U
Height432 mm
Width85 mm
Depth508 mm
Color FamilyBlack
General Information
Product TypeDouble Conversion Online UPS
Manufacturer Part NumberSRTL3000RMXLI-NC
Manufacturer Website Addresshttp://www.schneider-electric.com.au
ManufacturerSchneider Electric SA
Product NameSmart-UPS SRT Li-Ion 3000VA RM 230V Network Card
Product LineSmart-UPS SRT
Brand NameAPC by Schneider Electric
Power Description
Input Voltage230 V AC
Output Voltage220 V AC
240 V AC
230 V AC
Surge Energy Rating432 J
Waveform TypePure Sine Wave
Output Frequency60 Hz
Input Frequency70 Hz
Load Capacity (VA)3 kVA
Load Capacity (Watt)2.70 kW
