Product Overview

APC by Schneider Electric Easy UPS On-Line Double Conversion Online UPS - 15 kVA/15 kW - Single Phase - 9U Rack-mountable - 6 Hour Recharge - 4.61 Minute Stand-by - 230 V AC, 415 V AC Input - 230 V AC, 220 V AC, 240 V AC Output - 1 x Hard Wire 3-wire (1P + N + E) - Sine Wave - Serial Port - USB - LCD Display

This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 15kVA double-conversion on-line 9U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRV comes with hard wire 3-wire(1P+N+E) and 5-wire(3P+N+E) inputs, and 3-wire(1P+N+E) outlet. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS.

Technical Specifications

Battery Information
Battery CharacteristicsValve-regulated
Display & Graphics
DisplayLCD
Physical Characteristics
Rack Height9U
Product ColorBlack
Interfaces/Ports
USBYes
Serial PortYes
EPO PortYes
Management
Network ManagementSmartSlot
RS-232
AlarmOn Battery
Overload
Low Battery
General Information
Product TypeDouble Conversion Online UPS
Manufacturer Part NumberSRV15KRILRK
Manufacturer Website Addresshttp://www.schneider-electric.com.au
Packaged Quantity1 Pack
ManufacturerSchneider Electric SA
Product NameEasy UPS On-Line SRV 15kVA Rack-Mountable UPS
Product LineEasy UPS On-Line
Product SeriesSRV
Brand NameAPC by Schneider Electric
Power Description
Input Voltage415 V AC
120 V AC
230 V AC
Waveform TypeSine Wave
Input Voltage Range110 V AC - 300 V AC
Miscellaneous
Package Contents
  • Easy UPS On-Line SRV 15kVA Rack-Mountable UPS
  • 1 x USB Cable
  • 1 x RS-232 Configuration Cable
  • 3 x Rack Mounting Brackets
  • 3 x Stabilization/wall Mounting Feet
  • 6 x Jumper Bar
  • 2 x External Battery Pack
  • 1 x Battery Cable
  • User Manual
Certifications & Standards
    • CE
    • UKCA
    • EN/IEC 62040-1:2019/A11:2021
    • EN/IEC 62040-2:2006/AC:2006
    • EN/IEC 62040-2:2018
Environmentally FriendlyYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)
China Restriction of Hazardous Substances (China RoHS)
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Technical Information
Application/UsageIT
Business
Network
Plug/Connector TypeHard Wire 5-wire (3P + N + E)
Hard Wire 3-wire (1P + N + E)
PhaseSingle Phase
Receptacle TypeHard Wire 3-wire (1P + N + E)
Receptacle Detail1 x Hard Wire 3-wire (1P + N + E)
