Product Overview

Easy UPS On-Line, 6kVA/6kW, Lithium-ion, Rack/Tower 5U, 230V, 1 Hard wire (1P+N+E) outlet, Intelligent Card Slot, Extended runtime, W/ rail kit

This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 6kVA double-conversion on-line lithium-ion 5U UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRVL comes with terminal block input and terminal block outlet. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9601l) that enables network-based UPS monitoring and management. With purchased Network Management Card and license, the UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The Emergency Power Off (EPO) function can remotely shut off the UPS in an emergency. It's ideal for Micro Data Center and Server room, Industrial Automation , Equipment Manufacturing. The UPS has a 3-year warranty and Lithium-Ion battery has a 5-year warranty. The SRVL comes with a easy-to-read 90 degree rotatable LCD display for detailed and accurate information on UPS status. This lithium-ion UPS is ideal for Industrial Automation, Telecommunications, Datacenter and Server rooms, Smart Buildings, Surveillance, and Power and Energy Management. Rack/ Tower convertible design with default accessory kit.

  • Keep your sensitive devices powered with a backup of up to 35 minute at full load
  • 6 kVA load capacity - work without any interruption during power outages
  • Prevent critical data loss by staying powered during a blackout with up to 6 kW load capacity

Technical Specifications

Display & Graphics
DisplayLCD
Interfaces/Ports
USBYes
Network (RJ-45)Yes
Serial PortYes
EPO PortYes
Miscellaneous
Certifications & Standards
    • CB
    • CE
    • UKCA
    • RCM
    • IRAM
    • TISI
    • UN 38.3
    • IEC 62619
Environmentally FriendlyYes
Environmental ComplianceChina Restriction of Hazardous Substances (China RoHS)
Restriction of Hazardous Substances (RoHS)
Management
Network ManagementSmartSlot
Intelligent Card Slot
AlarmOn Battery
Low Battery
Overload
Environmental Conditions
Thermal Dissipation1780 BTU/h
Minimum Operating Temperature0°C
Maximum Operating Temperature40°C
Maximum Operating Elevation3 km
Maximum Storage Elevation15 km
Sound Emission (A-Weighted)57.3 dB(A)
Battery Information
Battery Life10 Year
Battery ChemistryLithium Ion (Li-Ion)
Backup/Run Time (Half Load)1.13 Hour
Backup/Run Time (Full Load)35 Minute
Replaceable BatteryYes
DC System Voltage48 V DC
Typical Battery Recharge Time5 Hour
Power Description
Input Voltage120 V AC
230 V AC
Output Voltage240 V AC
220 V AC
230 V AC
Surge Energy Rating600 J
Waveform TypePure Sine Wave
Input Voltage Range186 V AC - 300 V AC
120 V AC - 300 V AC
Output Frequency50 Hz
60 Hz
Input Frequency70 Hz
40 Hz
Load Capacity (VA)6 kVA
Load Capacity (Watt)6 kW
Physical Characteristics
Weight (Approximate)69.20 kg
Rack Height5U
Height217 mm
Width438 mm
Depth685 mm
Product ColorBlack
Silver
Color FamilyDual Colour
General Information
Product TypeDouble Conversion Online UPS
Manufacturer Part NumberSRVL6KRILRK
Manufacturer Website Addresshttp://www.schneider-electric.com.au
Packaged Quantity1
ManufacturerSchneider Electric SA
Product NameEasy UPS On-Line 6000VA SRVL Tower/rack convertible UPS
Product LineEasy UPS On-Line
Product SeriesSRVL
Brand NameAPC by Schneider Electric
Technical Information
Application/UsageServer
Data Center
IT
Industrial Automation System
Equipment
Energy Management System
Building System
Network
Electronic
Surveillance System
Telecommunication
Workstation
Plug/Connector TypeTerminal Block
Hard Wire 3-wire (1P+N+E)
PhaseSingle Phase
Receptacle TypeTerminal Block
Hard Wire 3-wire (1P + N + E)
Receptacle Detail1 x Hard Wire 3-wire (1P + N + E)
