4 Port Gigabit PoE PCIe Network Card
4 Port Gigabit PoE PCIe Network Card
Product Overview
StarTech.com Gigabit Ethernet Card for Computer - 10/100/1000Base-T - Plug-in Card - PCI Express x4 - 4 Port(s) - 4 - Twisted Pair
The ST4000PEXPSE 4-Port PoE NIC lets you add four Gigabit Power over Ethernet ports through a single PCI Express slot. Each port can provide up to 25.5W of power, combining network data and power over a single Ethernet cable for reduced cable clutter and added convenience for remote PoE devices.
The PCI express PoE card supports the IEEE 802.3at (Type 1 and 2) standard for Power Sourcing Equipment (PSE), and can deliver up to 48V DC power to compliant Powered Devices (PD). This eliminates the need for a separate power source and data connection for PoE devices such as IP cameras, IP phones or wireless access points.
Suitable for any standard profile PCIe-enabled client, server or workstation, the PoE network card supports features such as Jumbo Frames (up to 9KB), VLAN tagging and Wake on LAN (WoL).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
- Enjoy superfast data transfer of up to 2000 MB/s with PCI Express x4 card, between the network card and motherboards
- Supports cost-efficient twisted pair cables for speedy data transfer up to 100 meters
- With the 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over the twisted pair cable
- This Gigabit Ethernet card guarantees a replacement networking interface to client, server or workstation
- With quad ports on a single card, save valuable expansion slots on your system for other purposes
Technical Specifications
| Media Type Supported | Twisted Pair |
| Product Type | Gigabit Ethernet Card |
| Manufacturer Part Number | ST4000PEXPSE |
| Manufacturer Website Address | http://www.startech.com/au |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Name | 4 Port Gigabit Power over Ethernet PCIe Network Card - PSE / PoE PCI Express NIC |
| Brand Name | StarTech.com |
| Environmentally Friendly | Yes |
| Network Technology | 10/100/1000Base-T |
| Number of Network (RJ-45) Ports | 4 |
| Total Number of Ports | 4 |
| Thickness | 17.8 mm |
| Form Factor | Plug-in Card |
| Height | 119.4 mm |
| Width | 238.8 mm |
