Product Overview
StarTech.com 2 Port USB DisplayPort KVM Switch with Audio - 2 Computer(s) - 1 Local User(s) - WQUXGA - 3840 x 2400 - 6 x USB - 3 x DisplayPort - Desktop
The SV231DPUA 2-Port USB DisplayPort KVM Switch delivers dual computer KVM control, for demanding high definition multimedia applications. Supporting DisplayPort connections with a native resolution of 2560 x 1600, and support for both 7.1 HD digital audio (when connected to supporting displays and sources) and 3.5mm stereo analog audio/mic.
A simple, yet comprehensive KVM solution, the 2-port switch features both front-panel push-buttons and hotkey switching, and offers a small form factor design with connection ports situated on the rear panel. A Plug-and-Play USB 2.0 hub port allows you to share an additional USB peripheral between the 2 connected computers, avoiding the expense of purchasing duplicate peripheral devices.
A suitable solution for medical applications (MRI, X-ray diagnostics etc.), the KVM switch supports a maximum resolution of 3840 x 2400 at a reduced refresh rate.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
- Compatible with Mini-DisplayPort adapters, making it suitable for Apple MacBook® connectivity
- Support for both analog and digital audio sources provides the versatility to use either connection depending on preference/availability
- USB peripheral sharing eliminates the expense of duplicate devices (printers, scanners, etc.)
Technical Specifications
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Input Voltage | 5 V DC |
| Input Voltage Range | 100V AC to 240V AC |
| Number of Computers Supported | 2 |
| Number of Local Users Supported | 1 |
| Product Type | KVM Switchbox |
| Manufacturer Part Number | SV231DPUA |
| Manufacturer Website Address | http://www.startech.com/au |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Name | 2 Port USB DisplayPort KVM Switch with Audio |
| Brand Name | StarTech.com |
| Maximum Video Resolution | 3840 x 2400 |
| Graphic Mode | WQUXGA |
| USB | Yes |
| Number of USB Ports | 6 |
| DisplayPort | Yes |
| Number of DisplayPorts | 3 |
| Weight (Approximate) | 1.10 kg |
| Form Factor | Desktop |
| Height | 43.2 mm |
| Width | 221 mm |
| Depth | 129.5 mm |
| Product Color | Black |
