DOCK - THUNDERBOLT 3 DUAL 4K 85W PD
DOCK - THUNDERBOLT 3 DUAL 4K 85W PD
Product Overview
StarTech.com Thunderbolt 3 Docking Station for Notebook - 85 W - Black, Grey - Certified Thunderbolt 3 docking station with dual monitor 4K 60Hz DisplayPort + TB3 (USB-C), 85W Power Delivery, 2x USB-A, 1x USB-C, GbE, audio - Macbook Pro / Air, macOS, Windows - Incl. TB3 cable, USB-C to DP adapter - Daisychain TB3 devices
Easily transform your Thunderbolt 3™ equipped MacBook Pro or Windows laptop into a dual-4K workstation with up to 40Gbps of throughput. The high-quality TB3 dock features three USB 3.0 ports, 85W Power Delivery to charge your laptop.
Create a Dual-4K Workstation
Great for video editing and other Ultra HD tasks, this dual-4K monitor docking station supports 40Gbps speeds and 4K resolution on two monitors. Run resource-demanding applications on two independent displays, without draining system resources.
Connect your laptop to:
- 1 x 4K monitor via the DP Port
- 1 x 4K monitor via the TB3 USB-C Port (1.8 m cable included)
OR
- 1 x 5K monitor via the DP & TB3 USB-C port
Easy Installation & Deployment
Simply connect the TB3 dock to your laptop with included TB3 cable and start working immediately. No time-consuming driver installations are required.
Connect your Devices
With three USB 3.0 ports, the Thunderbolt 3 docking station gives you plenty of ports for the latest and legacy devices. Connect USB devices like flash drives using the two Type-A ports. Keep your mobile device charged with the dock's Fast-Charge and sync port. Connect a USB-C device with the USB-C port (5Gbps - data only).
Plenty of Charging Power
The Thunderbolt 3docking station features a 170W power adapter supporting Power Delivery to power and charge (up to 85W) your laptop, while powering all your devices connected to the dock. This eliminates the need to use two separate power adapters for your laptop and dock.
Connected Device Transparency with the StarTech.com MAC Address Changer Utility
The TB3DK2DPPD, includes a free Windows® application that enables you to better manage your enterprise network security. When you connect to your network through the ethernet port of the dock, the computer's MAC address is typically not broadcast to the network, as your network only sees the MAC address of the docking station. However, the StarTech.com MAC Address Changer or Cloning software enables the USB-C dock to use MAC address spoofing of the connected Windows laptop rather than the MAC address of the dock itself. This ensures your network administrators have full visibility of each device on the network and can monitor and limit activity accordingly. To request access to our MAC Address Changer utility, please contact our Technical Support Department by phone, live chat , or e-mail .
TB3DK2DPPD features a rugged aluminum casing and is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Technical Specifications
Ethernet Technology | Gigabit Ethernet |
Maximum Power Supply Wattage | 85 W |
Operating System Supported | Windows |
macOS |
Compatibility |
|
Environmentally Friendly | Yes |
Brand Compatibility | HP |
Apple | |
Lenovo | |
Dell |
Host Interface | Thunderbolt 3 |
Network (RJ-45) | Yes |
Audio Line Out | Yes |
DisplayPort | Yes |
Number of DisplayPort Outputs | 1 |
Total Number of USB Ports | 5 |
Number of USB 3.0 Ports | 2 |
Thunderbolt | Yes |
USB Type-C | Yes |
USB Type-C Detail | 1 x USB Type-C (24 pin) USB 3.0 (5Gbps) Female |
USB Type-A | Yes |
Weight (Approximate) | 450 g |
Length | 220 mm |
Height | 27 mm |
Width | 80 mm |
Product Color | Black |
Grey |
Device Supported | Notebook |
Connectivity Technology | Wired |
Number of Displays Supported | 2 |
Supported Resolutions | 3840 x 2160 |
4096 x 2160 | |
Screen Mode Supported | 4K |
Product Type | Docking Station |
Manufacturer Part Number | TB3DK2DPPD |
Manufacturer Website Address | http://www.startech.com/au |
Packaged Quantity | 1 |
Manufacturer | StarTech.com |
Product Name | Dual 4K Monitor Thunderbolt 3 Dock with 3x USB 3.0 Ports |
Brand Name | StarTech.com |
