UA-Button
Product Overview
| Mechanical | |
|---|---|
| Dimensions | 137 x 88 x 38.1 mm (5.4 x 3.5 x 1.5") |
| Weight | 180 g (6.3 oz) |
| Enclosure material | Polycarbonate |
| Mounting material | Metal |
| Color | Black/white |
| Hardware | |
| Contact type | (1) Normal open |
| Contact rating | 30V DC, 2A |
| Mechanical life | 1,000,000 clicks |
| Environment | Indoor only |
| Storage temperature | -40 to 70° C (-40 to 158° F) |
| Ambient operating temperature | -10 to 40° C (14 to 104° F) |
| Ambient operating humidity | 5 to 90% noncondensing |
| Certification | CE |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | 137 x 88 x 38.1 mm (5.4 x 3.5 x 1.5") |
| Weight | 180 g (6.3 oz) |
| Enclosure material | Polycarbonate |
| Mounting material | Metal |
| Color | Black/white |
| Hardware | |
| Contact type | (1) Normal open |
| Contact rating | 30V DC, 2A |
| Mechanical life | 1,000,000 clicks |
| Environment | Indoor only |
| Storage temperature | -40 to 70° C (-40 to 158° F) |
| Ambient operating temperature | -10 to 40° C (14 to 104° F) |
| Ambient operating humidity | 5 to 90% noncondensing |
| Certification | CE |
