UFP-VIEWPORT
Product Overview
| Mechanical | |
|---|---|
| Dimensions | 157 x 52 x 37 mm (6.2 x 2.1 x 1.5") |
| Weight | Without mount: 230 g (8.1 oz) With TV mount: 252 g (8.9 oz) |
| Enclosure material | Polycarbonate |
| Mount material | Polycarbonate |
| Hardware | |
| Processor | Octa-core ARM® |
| Memory | 4 GB low power DDR4X |
| Networking interface | (1) GbE RJ45 port |
| Power method | PoE |
| Max. power consumption | 9.5W |
| ESD/EMP protection | Air: ± 8kV, contact: ± 4kV |
| Bluetooth | 5.0 |
| Antennas | Bluetooth |
| Antenna gain | 2 dB |
| Button | Factory-reset |
| Ambient operating temperature | 0 to 40° C (32 to 104° F) |
| Ambient operating humidity | 20 to 80% noncondensing |
| Certifications | FCC, IC, CE |
| Software | |
| Web application | UniFi Protect |
| Mobile app | UniFi Protect iOS™ and Android™ |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | 157 x 52 x 37 mm (6.2 x 2.1 x 1.5") |
| Weight | Without mount: 230 g (8.1 oz) With TV mount: 252 g (8.9 oz) |
| Enclosure material | Polycarbonate |
| Mount material | Polycarbonate |
| Hardware | |
| Processor | Octa-core ARM® |
| Memory | 4 GB low power DDR4X |
| Networking interface | (1) GbE RJ45 port |
| Power method | PoE |
| Max. power consumption | 9.5W |
| ESD/EMP protection | Air: ± 8kV, contact: ± 4kV |
| Bluetooth | 5.0 |
| Antennas | Bluetooth |
| Antenna gain | 2 dB |
| Button | Factory-reset |
| Ambient operating temperature | 0 to 40° C (32 to 104° F) |
| Ambient operating humidity | 20 to 80% noncondensing |
| Certifications | FCC, IC, CE |
| Software | |
| Web application | UniFi Protect |
| Mobile app | UniFi Protect iOS™ and Android™ |
