US-XG-6POE
Product Overview
| Mechanical | |
|---|---|
| Dimensions | 165 x 268.1 x 31.8 mm (6.5 x 10.6 x 1.3") |
| Weight | 1.3 kg (2.9 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (4) 1/2.5/5/10 GbE RJ45 ports (2) 10G SFP+ ports |
| PoE interface | (4) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
| Total non-blocking throughput | 60 Gbps |
| Switching capacity | 120 Gbps |
| Forwarding rate | 89.3 Mpps |
| Power method | (1) 54V DC, 3.88A power adapter (Included) (1) DC input with terminal block |
| Power supply | External AC/DC adapter (Included) DC power source |
| Supported voltage range | 44–57V DC |
| Max. power consumption | 40W (Excluding PoE output) |
| Total available PoE | 170W |
| Max. PoE wattage per port by PSE | PoE++: 60W |
| Voltage range PoE mode | PoE: 44—57V PoE+/PoE++: 50—57V |
| ESD/EMP protection | Air: ± 18kV, contact: ± 12kV |
| Button | Factory reset |
| Ambient operating temperature | -5 to 45° C (23 to 113° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | PoE Link/speed/activity |
| SFP+ | Link/activity |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | 165 x 268.1 x 31.8 mm (6.5 x 10.6 x 1.3") |
| Weight | 1.3 kg (2.9 lb) |
| Enclosure material | SGCC steel |
| Hardware | |
| Management interface | Ethernet In-Band |
| Networking interface | (4) 1/2.5/5/10 GbE RJ45 ports (2) 10G SFP+ ports |
| PoE interface | (4) PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-) |
| Total non-blocking throughput | 60 Gbps |
| Switching capacity | 120 Gbps |
| Forwarding rate | 89.3 Mpps |
| Power method | (1) 54V DC, 3.88A power adapter (Included) (1) DC input with terminal block |
| Power supply | External AC/DC adapter (Included) DC power source |
| Supported voltage range | 44–57V DC |
| Max. power consumption | 40W (Excluding PoE output) |
| Total available PoE | 170W |
| Max. PoE wattage per port by PSE | PoE++: 60W |
| Voltage range PoE mode | PoE: 44—57V PoE+/PoE++: 50—57V |
| ESD/EMP protection | Air: ± 18kV, contact: ± 12kV |
| Button | Factory reset |
| Ambient operating temperature | -5 to 45° C (23 to 113° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | Status |
| Ethernet | PoE Link/speed/activity |
| SFP+ | Link/activity |
