USC-M15W FHD P-CAP TOUCH
USC-M15W FHD P-CAP TOUCH
Product Overview
Advantech USC-M15WP-BST10 16" Class LED Touchscreen Monitor - 16:9 - 25 ms - 15.6" Viewable - Projected Capacitive - 1920 x 1080 - Full HD - 220 cd/m² - LED Backlight - Speakers - HDMI - USB - 1 x HDMI In - Black - 24 Month
15.6in - 16:9 Monitor - FHD - PCAP Touch - IP65 Front Panel - 1x HDMI - 1 x USB-C - 2 x 2W speaker - VESA75x75 - No Stand - 2 Years Warranty - Black- 15.6" Full HD LCD (LED backlight)
- Flat bezel-less P-CAP touch panel
- Supports VESA (75 x 75 mm) and single hinge stand
- IP65-rated front panel
- Compact, future-ready and simple design
- Optimize serviceability with USB-C cable connectivity
Technical Specifications
Miscellaneous
| Package Contents |
|
Touchscreen Information
| Touchscreen Type | Projected Capacitive |
Audio
| Speakers | Yes |
| Number of Speakers | 2 |
Video
| Brightness | 220 cd/m² |
| Maximum Resolution | 1920 x 1080 |
| Native Contrast Ratio | 1,000:1 |
Interfaces/Ports
| USB | Yes |
| HDMI | Yes |
| Number of USB Ports | 1 |
| Number of HDMI Inputs | 1 |
| Total Number of HDMI Ports | 1 |
| USB Type-C | Yes |
| Total Number of USB Type-C Ports | 1 |
Physical Characteristics
| Height | 230.5 mm |
| Width | 381 mm |
| Depth | 31.5 mm |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 75 x 75 |
| Product Color | Black |
| Color Family | Black |
General Information
| Product Type | LED Touchscreen Monitor |
| Manufacturer Part Number | USCM15WPBST10 |
| Manufacturer Website Address | http://www.advantech.com |
| Manufacturer | Advantech Co., Ltd |
| Product Model | USC-M15WP-BST10 |
| Product Name | USC-M15W 15.6" 16:9 FHD P-CAP Touchscreen Monitor |
| Product Series | USC-M15W |
| Brand Name | Advantech |
Technical Information
| Aspect Ratio | 16:9 |
| Response Time | 25 ms |
| Features | Bezel-less Design |
| Viewable Screen Size | 15.6" |
| Screen Mode | Full HD |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Backlight Technology | LED |
| Screen Size Class | 16" |
| Ingress Protection (IP) Rating | IP65 |
