USW-Flex-Utility
Product Overview
| Mechanical | |
|---|---|
| Dimensions | Enclosure: 249 x 218 x 60 mm (9.8 x 8.6 x 2.4") Adapter: 118.5 x 63 x 34.7 mm (4.7 x 2.5 x 1.4") |
| Weight | Enclosure: 740 g (26.1 oz) Adapter: 206 g (7.27 oz) |
| 60W PoE Adapter | |
| Output voltage | 54V, 1.11A |
| Rated voltage | 100-240V AC |
| Input current | Max. 1.5A |
| Efficiency | > 86% |
| Output ripple | 200mVpp |
| Line regulation | < 1% |
| Load regulation | < 3% |
| 4-pair powering | Pins 1, 2, 4, 5+ and Pins 3, 6, 7, 8- |
| Ambient operating temperature | -20 to 60° C (-4 to 140° F) |
| Storage temperature | -30 to 70° C (-22 to 158° F) |
| Ambient operating humidity | 5 to 90%, noncondensing |
| Surge immunity | 4kV difference and Common mode |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | Enclosure: 249 x 218 x 60 mm (9.8 x 8.6 x 2.4") Adapter: 118.5 x 63 x 34.7 mm (4.7 x 2.5 x 1.4") |
| Weight | Enclosure: 740 g (26.1 oz) Adapter: 206 g (7.27 oz) |
| 60W PoE Adapter | |
| Output voltage | 54V, 1.11A |
| Rated voltage | 100-240V AC |
| Input current | Max. 1.5A |
| Efficiency | > 86% |
| Output ripple | 200mVpp |
| Line regulation | < 1% |
| Load regulation | < 3% |
| 4-pair powering | Pins 1, 2, 4, 5+ and Pins 3, 6, 7, 8- |
| Ambient operating temperature | -20 to 60° C (-4 to 140° F) |
| Storage temperature | -30 to 70° C (-22 to 158° F) |
| Ambient operating humidity | 5 to 90%, noncondensing |
| Surge immunity | 4kV difference and Common mode |
