USW-Flex-XG

Product Overview

Mechanical
Dimensions	135 x 185 x 32 mm (5.3 x 7.3 x 1.3")
Weight	1.2 kg (2.7 lb)
Enclosure material	Polycarbonate
Hardware
Management interface	Ethernet In-Band
Networking interface	(1) GbE, PoE+ RJ45 port (4) 10 GbE RJ45 ports
Total non-blocking throughput	41 Gbps
Switching capacity	82 Gbps
Forwarding rate	61.012 Mpps
Power method	(1) PoE+, 50—57V DC, 25W (1) USB Type-C, 5V DC, 5A
Power supply	PoE+ (Pins 1, 2+/3, 6- or 4, 5+/7, 8-) AC/DC power adapter, 5V DC, 5A, 1.5 m cord (Included)
Supported voltage range	90—264V AC (Adapter)
Max. power consumption	25W
ESD/EMP protection	Air: ± 16kV, contact: ± 12kV
Button	Factory reset
Ambient operating temperature	-5 to 45° C (23 to 113° F)
Ambient operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
Switching Features
Layer 2 features	IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features	–
LEDs
System	Status
Ethernet	Speed/link/activity
Application Requirements
UniFi Network	Version 6.1.67 and later

Mechanical
Dimensions	135 x 185 x 32 mm (5.3 x 7.3 x 1.3")
Weight	1.2 kg (2.7 lb)
Enclosure material	Polycarbonate
Hardware
Management interface	Ethernet In-Band
Networking interface	(1) GbE, PoE+ RJ45 port (4) 10 GbE RJ45 ports
Total non-blocking throughput	41 Gbps
Switching capacity	82 Gbps
Forwarding rate	61.012 Mpps
Power method	(1) PoE+, 50—57V DC, 25W (1) USB Type-C, 5V DC, 5A
Power supply	PoE+ (Pins 1, 2+/3, 6- or 4, 5+/7, 8-) AC/DC power adapter, 5V DC, 5A, 1.5 m cord (Included)
Supported voltage range	90—264V AC (Adapter)
Max. power consumption	25W
ESD/EMP protection	Air: ± 16kV, contact: ± 12kV
Button	Factory reset
Ambient operating temperature	-5 to 45° C (23 to 113° F)
Ambient operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
Switching Features
Layer 2 features	IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs
Layer 3 features	–
LEDs
System	Status
Ethernet	Speed/link/activity
Application Requirements
UniFi Network	Version 6.1.67 and later

Current Price

AUD 580.91

Get expert advice from our technical team for installation and configuration help.
