UVC-AI-Bullet
Product Overview
| Mechanical | |
|---|---|
| Dimensions | Without mount: Ø82 x 88.3 mm (Ø3.2 x 3.5") With mount: Ø82 x 153 mm (Ø3.2 x 6") |
| Weight | Without mount: 628 g (1.4 lb) With mount: 765 g (1.7 lb) |
| Enclosure material | Aluminum alloy, polycarbonate |
| Mounting material | Wall mount: aluminum alloy Pole mount: aluminum alloy |
| Weatherproofing | IP65 |
| Resistance | IK04 |
| Optics | |
| Sensor | 5MP CMOS |
| Lens | Fixed focal length |
| View angle | H: 84.7°, V: 46.2°, D: 99° |
| Night mode | Built-in IR LED illumination and an IR cut filter |
| Video | |
| Resolution | 4MP 2688 x 1512 (16:9) |
| Max. frame rate | 30 FPS |
| Image settings | Brightness, contrast, sharpness, saturation, noise reduction, 50/60 Hz |
| System | |
| Processor | Quad-core Arm® Cortex®-A53 based chip |
| Networking interface | GbE RJ45 port |
| Max. power consumption | 7.68W |
| Power method | PoE |
| Supported voltage range | 37—57V DC |
| LED | R/G/B/W ring |
| Button | Factory reset |
| Mounting | Wall, pole mount (Included) |
| Ambient operating temperature | -20 to 40° C (-4 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| Audio | |
| Microphone | Yes (Can be disabled) |
| Software | |
| Web application | UniFi Protect: Version 1.20.0 and later |
| Mobile app | UniFi Protect iOS™: Version 1.5.6 and later UniFi Protect Android™: Version 1.4.7 and later |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | Without mount: Ø82 x 88.3 mm (Ø3.2 x 3.5") With mount: Ø82 x 153 mm (Ø3.2 x 6") |
| Weight | Without mount: 628 g (1.4 lb) With mount: 765 g (1.7 lb) |
| Enclosure material | Aluminum alloy, polycarbonate |
| Mounting material | Wall mount: aluminum alloy Pole mount: aluminum alloy |
| Weatherproofing | IP65 |
| Resistance | IK04 |
| Optics | |
| Sensor | 5MP CMOS |
| Lens | Fixed focal length |
| View angle | H: 84.7°, V: 46.2°, D: 99° |
| Night mode | Built-in IR LED illumination and an IR cut filter |
| Video | |
| Resolution | 4MP 2688 x 1512 (16:9) |
| Max. frame rate | 30 FPS |
| Image settings | Brightness, contrast, sharpness, saturation, noise reduction, 50/60 Hz |
| System | |
| Processor | Quad-core Arm® Cortex®-A53 based chip |
| Networking interface | GbE RJ45 port |
| Max. power consumption | 7.68W |
| Power method | PoE |
| Supported voltage range | 37—57V DC |
| LED | R/G/B/W ring |
| Button | Factory reset |
| Mounting | Wall, pole mount (Included) |
| Ambient operating temperature | -20 to 40° C (-4 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| Audio | |
| Microphone | Yes (Can be disabled) |
| Software | |
| Web application | UniFi Protect: Version 1.20.0 and later |
| Mobile app | UniFi Protect iOS™: Version 1.5.6 and later UniFi Protect Android™: Version 1.4.7 and later |
