UVC-AI-DSLR
Product Overview
| Mechanical | |
|---|---|
| Dimensions | Without mount: Ø80 x 89 mm (Ø3.1 x 3.5") With mount: Ø80 x 153 mm (Ø3.1 x 6") M. Zuiko Digital ED 17 mm PRO: Ø68.2 x 87 mm (Ø2.7 x 3.4") Outdoor case: Ø91.6 x 196.3 mm (Ø3.6 x 7.7") |
| Weight | Without mount: 660 g (1.5 lb) With mount: 820 g (1.8 lb) M. Zuiko Digital ED 17 mm PRO: 390 g (0.9 lb) Outdoor case: 510 g (1.1 lb) |
| Enclosure material | Aluminum alloy |
| Mount material | Wall mount: aluminum alloy Pole mount: aluminum alloy |
| Weatherproofing | IPX5 (With the outdoor case) |
| Optics | |
| Sensor | 4/3" 10MP CMOS |
| Lens | M. Zuiko Digital ED 17 mm ƒ/1.2 PRO |
| View angle | Wide: H: 52°, V: 39°, D: 65° |
| Video | |
| Resolution | 8MP 3840 x 2160 (16:9) |
| Max. frame rate | 30 FPS |
| Image settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR/3DNR/NR by motion, masking, text overlay |
| System | |
| Processor | Quad-core Arm® Cortex®-A53 based chip |
| Networking interface | GbE RJ45 port |
| Max. power consumption | 17.77W (With lens working) |
| Power method | PoE+ |
| Supported voltage range | 37—57V DC |
| Buttons | Factory reset Lens release key |
| Mounting | Wall, pole mount (Included) Tripot mount (Optional) |
| Ambient operating temperature | -20 to 40° C (-4 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| Audio | |
| Microphone | Yes* (Can be disabled) *Audio function will be disabled when using its outdoor case. |
| Speaker | Yes* *Audio function will be disabled when using its outdoor case. |
| Software | |
| Web application | UniFi Protect: Version 2.2.2 and later |
| Mobile app | UniFi Protect iOS™ and Android™: Version 1.7.0 and later |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | Without mount: Ø80 x 89 mm (Ø3.1 x 3.5") With mount: Ø80 x 153 mm (Ø3.1 x 6") M. Zuiko Digital ED 17 mm PRO: Ø68.2 x 87 mm (Ø2.7 x 3.4") Outdoor case: Ø91.6 x 196.3 mm (Ø3.6 x 7.7") |
| Weight | Without mount: 660 g (1.5 lb) With mount: 820 g (1.8 lb) M. Zuiko Digital ED 17 mm PRO: 390 g (0.9 lb) Outdoor case: 510 g (1.1 lb) |
| Enclosure material | Aluminum alloy |
| Mount material | Wall mount: aluminum alloy Pole mount: aluminum alloy |
| Weatherproofing | IPX5 (With the outdoor case) |
| Optics | |
| Sensor | 4/3" 10MP CMOS |
| Lens | M. Zuiko Digital ED 17 mm ƒ/1.2 PRO |
| View angle | Wide: H: 52°, V: 39°, D: 65° |
| Video | |
| Resolution | 8MP 3840 x 2160 (16:9) |
| Max. frame rate | 30 FPS |
| Image settings | Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR/3DNR/NR by motion, masking, text overlay |
| System | |
| Processor | Quad-core Arm® Cortex®-A53 based chip |
| Networking interface | GbE RJ45 port |
| Max. power consumption | 17.77W (With lens working) |
| Power method | PoE+ |
| Supported voltage range | 37—57V DC |
| Buttons | Factory reset Lens release key |
| Mounting | Wall, pole mount (Included) Tripot mount (Optional) |
| Ambient operating temperature | -20 to 40° C (-4 to 104° F) |
| Ambient operating humidity | 10 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| Audio | |
| Microphone | Yes* (Can be disabled) *Audio function will be disabled when using its outdoor case. |
| Speaker | Yes* *Audio function will be disabled when using its outdoor case. |
| Software | |
| Web application | UniFi Protect: Version 2.2.2 and later |
| Mobile app | UniFi Protect iOS™ and Android™: Version 1.7.0 and later |
