Catalyst 2960 Plus 24 10/100 PoE + 2 T/S
Catalyst 2960 Plus 24 10/100 PoE + 2 T/S
Product Overview
CATALYST 2960 PLUS 24 10/100 POE + 2 T/S
Catalyst 2960+24PC-S Ethernet Switch with LAN Base software are a family of fixed-configuration, standalone intelligent Ethernet devices with Power Over Ethernet (PoE) or non-PoE configurations that provide desktop Fast Ethernet and Gigabit Ethernet connectivity, enabling enhanced LAN services for entry-level enterprise, mid market, and branch office networks. The Catalyst 2960-48PST-L Ethernet Switch offers integrated security, including Network Admission Control (NAC), advanced quality of service (QoS), and resiliency to deliver intelligent services for the network edge.
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Rack mounting enables you to organize wires & secure cables for professional installation
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
- With leading Layer 2 support, experience enhanced convenience, secure business operations, and a borderless network experience
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Cascade to other network devices through the uplink port to expand your local area network
- Electrical power is transmitted along with data in a single cable to devices such as Access Points, IP cameras or IP phones
- Quickly and easily set up a wired network with 26 networking ports
Technical Specifications
| Additional Information | LAN Lite Image |
| Layer Supported | 2 |
| Management |
|
| Manageable | Yes |
| Network Technology | 10/100/1000Base-T |
| 10/100Base-TX | |
| Ethernet Technology | Gigabit Ethernet |
| Flash Memory | 32 MB |
| Standard Memory | 64 MB |
| Memory Technology | DRAM |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | WS-C2960+24PC-S |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 2960+24PC-S |
| Product Name | Catalyst 2960+24PC-S Ethernet Switch |
| Product Line | Catalyst |
| Product Series | 2960 |
| Brand Name | Cisco |
| Power Source | Power Supply |
| PoE (RJ-45) Port | Yes |
| Redundant Power Supply Supported | Yes |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Shared SFP Slot | Yes |
| Total Number of Expansion Slots | 2.0 |
| Uplink Port | Yes |
| Number of PoE (RJ-45) Ports | 24 |
| Total Number of Network Ports | 26 |
| Port/Expansion Slot Details | 24 x Fast Ethernet Network |
| 2 x Gigabit Ethernet Uplink | |
| 2 x Gigabit Ethernet Expansion Slot |
| Weight (Approximate) | 5.40 kg |
| Form Factor | Rack-mountable |
| Height | 43.9 mm |
| Width | 444.5 mm |
| Depth | 330.2 mm |
| Compatible Rack Unit | 1U |
