Product Overview
Cisco Catalyst 3850 12 Port GE SFP IP Ba
The Cisco® Catalyst® 3850 Series is the next generation of enterprise-class stackable Ethernet access and aggregation layer switches that provide full convergence between wired and wireless on a single platform. Cisco's new Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility and application optimization. This convergence is built on the resilience of the new and improved Cisco StackWise-480 technology. The Cisco Catalyst 3850 Series Switches support full IEEE 802.3at Power over Ethernet Plus (PoE+), Cisco Universal Power over Ethernet (Cisco UPOE), modular and field-replaceable network modules, RJ45 and fiber-based downlink interfaces, and redundant fans and power supplies.- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Supports layer 3 switching for enhanced performance and usability
- Management capability provides control over setup and configuration of your network
- Supports optical fibre cable to span longer distances and provided high data transmission rates between servers and network components
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Stack port provides an easy and hassle-free way to extend your office network
Technical Specifications
Network & Communication
| Layer Supported | 3 |
Reliability
| MTBF | 315840 Hour |
Management & Protocols
| Management |
|
| Manageable | Yes |
Power Description
| Power Source | Power Supply |
| PoE (RJ-45) Port | No |
Memory
| Flash Memory | 2 GB |
| Standard Memory | 4 GB |
| Memory Technology | DRAM |
Miscellaneous
| Package Contents |
|
| Certifications & Standards |
IEEE Standards: EMC: Safety: |
| Environmentally Friendly | Yes |
Media & Performance
| Network Technology | 1000Base-X |
| Ethernet Technology | Gigabit Ethernet |
| 10 Gigabit Ethernet | |
| Media Type Supported | Optical Fiber |
Interfaces/Ports
| Token Ring Port | No |
| LRE Port | No |
| Modular | Yes |
| Management Port | Yes |
| Stack Port | Yes |
| Port/Expansion Slot Details | 15 x Gigabit Ethernet Expansion Slot |
I/O Expansions
| Expansion Slot Type | SFP |
| Network Interface Module (NIM) | |
| Number of SFP Slots | 12 |
| Shared SFP Slot | No |
| Total Number of Expansion Slots | 15.0 |
Physical Characteristics
| Weight (Approximate) | 7.02 kg |
| Form Factor | Rack-mountable |
| Desktop | |
| Height | 44.5 mm |
| Width | 444.5 mm |
| Depth | 449.6 mm |
| Compatible Rack Unit | 1U |
General Information
| Product Type | Layer 3 Switch |
| Manufacturer Part Number | WS-C3850-12S-S |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | WS-C3850-12S-S |
| Product Name | Catalyst WS-C3850-12S-S Layer 3 Switch |
| Product Line | Catalyst |
| Product Series | 3850 |
| Brand Name | Cisco |
