Product Overview
ZBOX CI331 nano (Barebone) - Celeron N5100 - Dual Gigabit Ethernet, Wi-Fi 5 and Bluetooth 5 - VESA Mount Ready - 2 x USB 3.1 ports, 2 x USB 3.0 ports (1 Type-C), 1 x USB 2.0 port
The ZBOX CI331 nano features a power-ecient and next-generation Intel processor to give you a silent experience in a compact PC. A robust passive cooled design with no moving components brings high reliability and extended durability. The signature honeycomb vents throughout the chassis enhances exhaust flow, backed by a large aluminum heatsink that maximizes heat transfer from the CPU to keep the system operating with performance. A VESA mount is included for nimble placement almost anywhere. The ZBOX CI331 nano is the ideal compact PC for home theater, digital signage, light productivity, everyday tasks, and more.- Intel Clear Video HD technology
- Intel Quick Sync Video technology
- Native 4K output
- WiFi 5 & Bluetooth 5
- Microsoft DirectX 12 compatible
Technical Specifications
Chipset
| Chipset Manufacturer | Intel |
Controllers
| Controller Type | Serial ATA/600 |
Miscellaneous
| Package Contents |
|
Display & Graphics
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
Network & Communication
| Bluetooth | Yes |
| Wireless LAN | Yes |
Operating System
| Operating System Supported | Windows 10 x64 |
| Windows 11 x64 |
Memory
| Maximum Memory Supported | 16 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2933/PC4-23466 |
| Total Number of Memory Slots | 2.0 |
Processor
| Processor Speed | 1.10 GHz |
| Processor Type | Celeron |
| Processor Model | N5100 |
| Processor Core | Quad-core (4 Core) |
| Processor Manufacturer | Intel |
| Maximum Turbo Speed | 2.80 GHz |
Physical Characteristics
| Form Factor | Mini PC |
| Height | 56.8 mm |
| Width | 126.8 mm |
| Depth | 127.8 mm |
Interfaces/Ports
| Total Number of USB Ports | 5 |
| Number of VGA Ports | 1 |
| USB Type-C Detail | 2 x USB 3.0 port (1 Type-C) |
| HDMI (Rear) | Yes |
| USB Type-C (Front) | Yes |
General Information
| Product Type | Barebone System |
| Manufacturer Part Number | ZBOXCI331NANO |
| Manufacturer Website Address | http://www.zotac.com/au/ |
| Manufacturer | ZOTAC International |
| Product Model | ZBOX-CI331NANO |
| Product Name | ZBOX CI331 nano |
| Product Line | ZBOX |
| Product Series | C |
| Brand Name | Zotac |
