Product Overview

DT Printer ZQ521 4.45in/113mm Eng/Trd Ch/Korean fonts RFID Dual 802.11ac/Bluetooth 5.2 ready stnd battery APAC certs Group A ID/TW/KR/MY/AU/NZ/LK/IN

Exceptional durability and reliability for the toughest environments

Zebra's ZQ500™ Series just got tougher. The premium ZQ511™ and ZQ521™ printers - both available in RFID models - give you best-in-class, rugged mobile printing for applications in any industry. Experience ultimate durability. Engineered for tough, demanding indoor and outdoor conditions, these printers can withstand significant drops, tumbles, accidents and environmental extremes that are common in mobile workplaces. Additional features, enhanced durability and military-grade design mean this printer will work as hard as you do.

Tough. Reliable. Built to Endure.

The Most Rugged Printers on the Market

You need a mobile printer that can handle serious abuse. Designed and certified to meet MIL-STD 810G for drop and shock, and tumble tested per the IEC68-2-32 spec to handle 1300 tumbles from 3.3' (1M), the ZQ511 and ZQ521 printers can withstand more than the average mobile printer.

Protection from solid and liquid ingress is no problem with an IP54 rating right out of the box without the need for a protective case.

If this isn't enough to convince you that these are ultra-rugged mobile printers, we also offer an optional exoskeleton case that increases our standard drop testing from 6.6' to 10' and improves the IP rating to IP65.

Built to Last

New over-molding helps increase the longevity and keeps your ZQ500 Series looking good over the life of the printer.

Print it All: Receipts, RFID tags, Labels and Linerless

Optimized for on-demand receipt printing in 3" (72mm) and 4" (104mm) print widths, the ZQ511 and ZQ521 printers also print a variety of labels including UHF RFID tags for all your tracking needs. Zebra's comprehensive RFID portfolio is the only one to include mobile printers to help you reduce errors, and print and encode RFID labels on the go.

On-the-Go Power, Functionality and Premium Performance

Get All the Benefits of Linerless Media

Eliminate waste and improve your company's green initiative with linerless printing. Linerless media also allows your workforce to spend less time disposing waste and more time on the task at hand - improving your workforce productivity. And, since there are more labels on a roll, there are fewer rolls of media to carry and fewer media roll changes.

Optimize Your Printing Quality and Power

Consistent outstanding print quality and performance are key. New printhead and print mechanism, as well as new processor and added memory, deliver it. Keep your employees on task and on schedule with the ZQ500 Series' secondary Bluetooth communication channel. Send print jobs to the printer via one channel, while a second channel performs additional functions such as device management.

  • Android, Apple iOS, Windows Mobile connectivity
  • Bluetooth specification 4.1 EDR + LE
  • WLAN 802.11ac
  • Fast roaming 802.11r supported
  • 528 MHz ARM processor
  • 3250 mAh PowerPrecision+ (retrievable, rechargeable Li-Ion)
  • USB On-The-Go ports (with optional strain relief)
  • Power Smart Print Technology - anticipates upcoming printing to optimize battery consumption and print speed
  • Direct thermal printing of barcodes, text and graphics
  • IP54 rated for protection against solid and liquid ingress

Technical Specifications

Interfaces/Ports
USBYes
Technical Information
Application/UsageMobile
Barcode Symbology SupportedIndustrial 2 of 5
UPC-E with EAN 2 or 5 Digit Extension
UPC-E
UPC-A
UCC/EAN 128
TLC 39
Standard 2 of 5
2 and 5 Digits Add-on
2D
AZTEC
Codabar
Codabar (NW-7)
Codablock
Code 11
Code 128
Code 39
Code 49
Code 93
Data Matrix
EAN-13
EAN-8
FIM
GS1 DataBar
Interleaved 2 of 5
ISBT-128
LOGMARS
Maxi Code
Micro PDF-417
MSI
MSI PLESSEY
PDF-417
Planet Code
Plessey
POSTNET
QR Code
Maximum Print Width103.89 mm (4.09")
Recommended UseLabel/Receipt Print
Connectivity TechnologyWireless
FeaturesRFID Encoder
Drop Resistant
Rugged
Shock Resistant
Mobile Device PrintingYes
Print Color CapabilityMonochrome
Maximum Print Length990.60 mm
Real Time ClockYes
Maximum Print Resolution (dpi)203
Memory
Standard Memory256 MB
Display & Graphics
Display ScreenYes
Display Screen TypeLCD
Fonts & Emulation
Language EmulationCPCL
ZPL
ZBI
Miscellaneous
Platform SupportedPC
iOS
Android
Network & Communication
BluetoothYes
Wireless LANYes
RFIDYes
Near Field Communication (NFC)Yes
Physical Characteristics
Weight (Approximate)784.7 g
Height66 mm
Width154.9 mm
Depth157.5 mm
General Information
Product TypeDirect Thermal Printer
Manufacturer Part NumberZQ52-BAW030A-00
Manufacturer Website Addresshttp://www.zebra.com/ap/en.html
ManufacturerZebra Technologies Corporation
Product ModelZQ521
Product NameZQ521 Direct Thermal Printer
Product SeriesZQ500
Brand NameZebra
Media Types & Handling
Media Thickness139.7 µm
Maximum Roll Diameter56.90 mm
Media TypeRFID Label
Receipt
Label
Linerless
Black Mark
Gap
Tag
Media SensorBlack Mark Sensor
Maximum Label Width113.03 mm
