DT PRINTER ZQ620 PLUS 3in/72MM ENGLISH T

DT PRINTER ZQ620 PLUS 3in/72MM ENGLISH T

DT PRINTER ZQ620 PLUS 3in/72MM ENGLISH T

Product Overview

DT Printer ZQ620 Plus 3in/72mm English Trad Chinese Korean fonts Dual 802.11AC / BT4.x Linered platen 0.75in core Group A Belt clip

Want to improve inventory management and customer service in your store? With the ZQ600/ZQ600 Plus Series mobile printer, you can. The ZQ600/ZQ600 Plus Series takes Zebra's popular QLn platform and makes it even better-adding advanced technology and innovative design that drive productivity, ease-of-use and manageability to a new level. A large color display takes all the guesswork out of printer status. Advanced battery technology and more battery capacity, power every minute of the longest shift. The instant wake-up feature ensures the ZQ600/ZQ600 Plus Series never sleeps on the job. Your workers get the fastest, most dependable wireless connections inside the four walls and your IT department will find the ZQ600/ZQ600 Plus Series easier to integrate, manage, setup and secure. The ZQ600/ZQ600 Plus Series- the next evolution in the gold standard for mobile label and receipt printing. The ZQ600 Plus Series delivers the same features and specifications as the ZQ600 Series, using redesigned electronics for long-term product continuity and availability. The ZQ600 Plus printers require new, different firmware and drivers.
Premium Features for Maximum Productivity
The Latest Wireless Connections
The ZQ600/ZQ600 Plus Series offers the fastest, most dependable wireless connections inside the four walls. With support for 802.11ac Wi-Fi and its latest security protocols, plus Bluetooth® Classic and Low Energy (BLE), your workers can count on blazing fast and secure connections.
Industry-Standard 802.11r Fast Roaming for Seamless Access
With support for 802.11r fast roaming technology, your workers can depend on a connection while they are on the move.
Instant Wake-Up Over Wi-Fi
This intelligent printer enters sleep mode when it is idle, and automatically wakes up the moment the user sends a print job. And the ZQ600/ZQ600 Plus Series' instant wake-up works over both Wi-Fi and Bluetooth.
Large Color Display Makes Configuration and Operation a Snap
The ZQ600/ZQ600 Plus Series provides a large display, userfriendly interface and easily customized menu. The ZQ600/ZQ600 Plus Series is based on Zebra's Link-OS menu system to deliver a common user experience across other Zebra Link-OS mobile, desktop and industrial printers.
Business Tough-Built for All-Day Every Day Enterprise Use
While the ZQ600/ZQ600 Plus Series is lightweight and comfortable to wear all shift long, it is loaded with features that give it longlasting durability, including over-molding, a tempered-glass display and seamless one-piece design. The high-grade resin is one of the toughest plastics available for greater impact resistance.
Unsurpassed Battery Power Management
Do More on a Single Charge
With the ZQ600/ZQ600 Plus Series' high-capacity 3250 mAH (ZQ610 and ZQ610 Plus / ZQ620 and ZQ620 Plus) and 6800 mAH (ZQ630 and ZQ630 Plus) battery, you can be sure that every worker has plenty of power for every shift. Plus Power Smart Print Technology™, Zebra's patented technology, maximizes efficiency by delivering the exact amount of power required for the highest quality printing, saving an estimated 20 to 30 percent of battery power
  • Produce high-quality documents with this monochrome printer to increase your productivity
  • A smart and inexpensive solution to print temporary documents
  • This printer produces high-quality labels and receipts
  • Bye bye Wires, Hello Wi-Fi! Cut down the potential hazards of tripping and electrical fires by reducing the number of long cables. Print wirelessly even from your mobile devices.

Technical Specifications

Battery Information
Battery Capacity3250 mAh
Technical Information
Application/UsageIndustrial
Desktop
Mobile
Barcode Symbology SupportedEAN-8
UPC E with 2 and 5 add on
2 and 5 Digits Add-on
AZTEC
Codabar (NW-7)
Code 128
Code 39
Code 93
Data Matrix
EAN-13
UPC-A
FIM
GS1 DataBar
Interleaved 2 of 5
Maxi Code
Micro PDF-417
MSI PLESSEY
PDF417
POSTNET
QR Code
TLC 39
UCC/EAN 128
Maximum Print Width72 mm (2.83")
Recommended UseLabel/Receipt Print
FeaturesShoulder Strap
Water Resistant
Belt Clip
Dust Resistant
Mobile Device PrintingYes
Print Color CapabilityMonochrome
Maximum Print Length813 mm
Character SetsUniversal Font Scaling Technology (UFST)
Agfa Monotype
Optional ConnectivityUSB
Ethernet
Serial (RS-232)
Wireless LAN
Ingress Protection (IP) RatingIP54
Maximum Print Resolution (dpi)203
Display & Graphics
Display ScreenYes
Memory
Standard Memory256 MB
Network & Communication
BluetoothYes
Wireless LANYes
Near Field Communication (NFC)Yes
Fonts & Emulation
Language EmulationZPL
CPCL
EPL
ZBI 2.0
Miscellaneous
Platform SupportediOS
PC
Android
Certifications & Standards

    Emissions:

    • FCC Part 15
    • Subpart B
    • EN55022 Class-B
    • EN60950
    • EN55024
    • VCCI class B


    Susceptibility:

    • EN55024
    • EN61000-4-2
    • EN61000-4-3
    • EN61000-4-4
    • EN61000-4-5


    Safety:

    • CE
    • TUV
    • CSA
Physical Characteristics
Weight (Approximate)730 g
Height77 mm
Width117.9 mm
Depth173.7 mm
General Information
Product TypeDirect Thermal Printer
Manufacturer Part NumberZQ62AAWAA0400
Manufacturer Website Addresshttp://www.zebra.com/ap/en.html
ManufacturerZebra Technologies Corporation
Product ModelZQ620 Plus
Product NameZQ620 Plus Direct Thermal Printer
Product SeriesZQ600
Brand NameZebra
Media Types & Handling
Media Thickness165.1 µm
Maximum Roll Diameter66.04 mm
Media TypeReceipt
Black Mark
Black Bar
Tag
Die-cut Label
Linered Media
Label
Gap
Media SensorBlack Mark Sensor
Gap Sensor
Maximum Label Width79.38 mm
Maximum Label Length812.80 mm
